This plug-in can help to set cable lines on drawings and get real architectural lengths of cables. It also helps to find and sum duplicates and export all the info to Excel file.

General Usage Instructions

1. SetMag

This command has 5 options:



a) Select MText or Text from the current drawing.

b) Create content of block using the User Input. Cable labels should be divided with ';'



   You can use templates of cables. You are able to use the following options:

   A1 - just on cable

   A1-10 - Cables A1,A2,A3...A10

   A1-A10 - same as above

   A1-10B - A1B,A2B...A10B

   A1-10B/2 - A1B,A3B,A5B,A7B,A9B

   You can write your own steps.



c) Using clipboard. You need to copy entries before the SetMag command. You can copy from Word, Excel or NotePad or from another AutoCAD Drawing.



d) Edit cable labels of block.



e) Edit length of polyline. You are able to add vertex or stretch vertex. After this you will be asked to use saved data. If you select «Yes» then you will have the same block.
    If «No» then you can create new block.



2. GetMag



This command asks you to select all drawings with AADB SetMag block



After this you have a lot of options to choose from.

1) Show duplicates.

2) Show duplicates in one file (.dwg).

3) Sum duplicates

4) Delete row



If something is wrong then you can always return to original information by using Get Original.

You also have Scale possibility. You have to use it before the end of command.

Final result is to get Excel file with all information.
