Automation Surfaces
Win64, EnglishGeneral Usage Instructions
When you have a surface with many polylines and you want to create a surface for each polyline, in this case, you must use the command SA-SPLIT.
- Just enter the new name
- Select the main surface
- After that select Polylines and wait for a minute and the application will create a surface for all selected polylines based on the main surface.
Create Multiple Surfaces Volumes, select the base surface, and then select any number of surfaces.
Commands
| Ribbon/Toolbar Icon | Command | Command Description |
|---|---|---|
|
SA-CreateSurfacesFromPolylines |
Create Surfaces From Polylines |
|
SA-CreateSurfacesFromPolylinesWi |
Create multiple surfaces from polylines with Text Name |
|
SA-CreateCropSurfacesFromPolylin |
Create Split Surfaces From Polylines |
|
SA-SurfaceCropedFromPolyLinesWit |
Create Split Surfaces From Polylines With Names |
|
SA-SurfaceFromGroups |
Create Surfaces From Groups |
|
SA-CreateSurfaceFromCorridorTopD |
Create Corridors Surfaces Top or Dutam Links |
|
SA-CreateCalculateVolumes |
Create Multiple Surfaces Volumes |
|
SA-ExtractBordersFromSurfaces |
Extract Border From Selected Surfaces |
|
SA-ExtractMajorMinorContours |
Extract Major and Minor Contours from Selected Surfaces |
|
SA-CreateMraiseSurfaces |
Create Multiple Raise Lower Surfaces |
|
SA-MOVETEXT2POLYLINE |
Move text to polyline elevation |
Installation/Uninstallation
The installer that ran when you downloaded this app/plug-in from Autodesk App Store will start installing the app/plug-in. OR, simply double-click the downloaded installer to install the app/plugin. You may need to restart the Autodesk product to activate the app/plug-in. To uninstall this plug-in, exit the Autodesk product if you are currently running it, simply rerun the installer, and select the "Uninstall" button. OR, click Control Panel > Programs > Programs and Features (Windows 10/11) and uninstall as you would any other application from your system.
Additional Information
Known Issues
Contact
Author/Company Information
Support Information
Version History
| Version Number | Version Description |
|---|---|
|
3.0.0 |
update user interface Add new commands |
|
2.1.0 |
Support 2025 Added commands |
