Digitally signed app
Toggles the surfaces in a drawing to a non-display style from a display style. Rerunning the command returns the surfaces to the original style they previously where when the command was run.
This program is useful when working with multiple surfaces in a drawing and you want to turn off all surface display in a drawing to remove cluttering contours, triangles, points, or other displayed properties of a surface.
About This Version
Version 1.5.0, 8/12/2022
Added SurfacesToggleAdd command. Digitally signed the msi.
sign in to write a review Get Technical Help
Just curious, what does this App do that Isolate Objects doesn't already do? "Right-Click" - Hide Selected objects?
You are correct you can hide the surfaces in the same manner as the Isolate Objects. The benefit in this command is you don't have to select any surfaces. Here is an old blog post on the command. http://blog.civil3dreminders.com/2012/12/toggle-surfaces.html There is also a feature in the SincPac that adds a command where you toggle on and off various surface components from the right click menu if you wish for more control. http://quuxsoft.com/ http://quuxsoft.com/SincpacC3D_Help/SP_ToggleSurfaceStyleDisplay.htm
I do a lot a LOT of feature line based site grading. With C3D this means multiple surfaces and multiple drawing files. Being able to control the display of all these surfaces is a BIG plus. Very good product!
This tool is a real joy to have. When working on a design we often need to turn surface displays off and on to get them out of the way or to inspect them after making changes. It is cumbersome to have to access prospector and change the surface styles everytime we need to turn them off and on. Having this tool on the Quick Access bar eliminates that hassle entirely. One pick and all the surfaces are off, pick again and they come back just as they were. For this price you can't go wrong. I HIGHLY recommend it.
