Copy Assistant will help you to copy Autodesk® Inventor® Part, Assembly files and its drawings (.idw and .dwg)

General Usage Instructions

Copy Assistant is set by default to copy the active document, but the user can select another document to be copied.

Please only select one document to be copied !!!

Once the document is selected, the user can choose between copying the document to the same path as the source Document or a different Path.

For Example:
I want to copy this document ( C:\Temp\MECH INVENTOR.ipt ), by default the program sets the path for the new document to be (C:\Temp).
If the user unchecked the Check Box (Copy to the same path as Source file), then the user must select a path for the New Document.

last Step:

You can tell the program to copy the drawing or not and this is done by checking the check box (Copy Drawing

The program searches the same folder of the source document for a drawing with the format .idw or .dwg once found, it will be copied.
if no Drawing is found in the Path, then you will get a message and you can choose to continue or to abort.


Replacing a component in .iam files
It also helps you when replacing a component in an Assembly.

You can replace any component and its drawing inside the assembly with a copy.

You can choose to replace all or only one Component.

Please follow the Instruction video!

https://www.youtube.com/watch?v=LrQf2rn3nf4&t=8s

Commands

Ribbon/Toolbar Icon Command Command Description

Copy_Assistant

Copy Assistant will help you to copy Inventor Part, Assembly files and its drawings

Installation/Uninstallation

The installer that ran when you downloaded this app/plug-in from Autodesk App Store will start installing the app/plug-in. OR, simply double-click the downloaded installer to install the app/plugin.

You can unload the plugin without uninstalling it by unchecking the "Loaded/Unloaded" checkbox associated with the plugin in the Inventor Add-In Manager. You may have to restart Inventor to completely unload the application.

To uninstall this plug-in, exit the Autodesk product if you are currently running it, simply rerun the installer, and select the "Uninstall" button. OR, you can uninstall it from 'Control Panel/Programs and Features' (Windows 7/8.1/10/11), just as you would uninstall any other application from your system.

Additional Information

Known Issues

Contact

Company Name: Blue Mech
Support Contact: info@bluemech.de

Author/Company Information

Blue Mech

Support Information

Version History

Version Number Version Description

23.1

This is the 3rd release of this App Copying in Model state mode Copying in Positional Representation mode

22.2

This is the 2nd release of this App Copying drawings is modified

22.1

This is the first release of this App.
