CPak DIN 11853 FOOD&CHEMICAL IND.CONTENT PACK 2024

CPak DIN 11853 FOOD&CHEMICAL IND.CONTENT PACK 2024

Win64, English

Princetech Engineering Services Pvt Ltd
Pipe & Fittings are as per DIN Standard.

General Usage Instructions

The package automatically locating the latest version of your Autodesk® AutoCAD® Plant 3D if you have multiple versions of P3D please change the location to which version you want.

Step 1: After Installation, the package will be located at “C:\AutoCAD Plant 3D 2024 Content\CPak Common”.

Step 2: Open AutoCAD Plant 3D and open an arbitrary drawing, typing the command: “PLANTREGISTERCUSTOMSCRIPTS” to register the custom script.

Step 3: Open your project folder and back up the “DefaultConnectorsConfig” .XML file.

Step 4: copy the customized end connection “DefaultConnectorsConfig” .XML file form FOOD & CHEMICAL INDUSTRY CONTENT PACK and paste it into your project.

Note: if you have already customized the end connection settings for your project then ignore the step 3 and 4.in that case use the project compare function to add the customized joint.

Step 5: Open AutoCAD Plant Spec Editor and open the file “C:\AutoCAD Plant 3D 2024 Content\CPak Common\CustomScripts\PEACS CPak ISO FOOD INDUSTRY CONTENT PACK”.

Step 6: Add the component from Catalog to your current spec and start modelling.

Commands

Installation/Uninstallation

Installation notes:

This catalog is compatible with Plant 3D 2019 and higher versions.

Uninstallation notes:

To uninstall this content pack, please go to Control Panel => Programs and Features => select the " CPak DIN FOOD & CHEMICAL INDUSTRY CONTENT PACK” => Uninstall.

Additional Information

Known Issues

Contact

Company Name: Princetech Engineering Services Pvt Ltd
Support Contact: plantinfo28@gmail.com

Author/Company Information

Princetech Engineering Services Pvt Ltd

Support Information

For questions about this content pack please contact: plantinfo28@gmail.com

Version History

Version Number Version Description

2023.0.0

Initial Release.
