Distribute MEP Elements from CAD

Distribute MEP Elements from CAD

Win64, English
BIM KIT
Distribute MEP Fixtures from CAD drawing such as (Lighting fixtures, Sprinklers, Electrical Equipment, Air Terminal …etc.) at different hosts (Ceiling, Floor, Reference plans, Wall).

General Usage Instructions

Usage steps:

  1. Select Model Element
  2. Select CAD Instance
  3. Choose host for element (Ceiling / Floor / Wall / Reference Plane)
  4. Choose CAD block
  5. The elements will be generated and placed as per the selected host for a CAD drawing

Screenshots

Commands

Installation/Uninstallation

The installer that ran when you downloaded this app/plug-in from Autodesk App Store will start installing the app/plug-in. OR, simply double-click the downloaded installer to install the app/plugin.

You may need to restart the Autodesk product to activate the app/plug-in.

To uninstall this plug-in, exit the Autodesk product if you are currently running it, simply rerun the installer, and select the "Uninstall" button. OR, click Control Panel > Programs > Programs and Features (Windows 10/11) and uninstall as you would any other application from your system.

Additional Information

Known Issues

Contact

Author/Company Information

BIM KIT

Support Information

Contact: mahmoudelrawy328@gmail.com

Version History

Version Number Version Description

1.2.0

Add Support to Autodesk® Revit® 2024 Using Entitlement API

1.1.0

Bug fixes.

1.0.0

Initial release.
