Column Axis

Column Axis

Win64, English

SALEM GROUP
Column Axis is a powerful design tool which is used for shifting rectangular column to the exact offsets from the grids.

General Usage Instructions

 Select a Structural rectangular Column and two perpendicular axes before pressing on the Button.

  • From SALEM GROUP tab > Tools panel > Press Column Axis button.
  • Determine base column corner that you wish from the four corner radio Buttons.
  • Determine the exact offset distances in Millimeter (mm) from the grids and press Apply button.
  • To create dimensions for the new location, select a Structural rectangular Column and two perpendicular axes, Choose the dimension style that you wish and then, Press Dimension Button.



 Notes:

  • This tool is used for Structural rectangular Column family only.
  • The offset distances are in millimeter (mm).
