ProtoTech's OBJ Exporter For Revit® - Trial
Win64, EnglishGeneral Usage Instructions
- Download and install the OBJ Exporter plugin for Revit.
- Run Revit and load a model (part or assembly).
- There’s a new tab on the ribbon bar named 'ProtoTech OBJ Exporter'.
It contains the following three ribbon buttons.
A) Export
1. After clicking Export, a 'Save As' dialog will display on our screen. You can write the name of the file.
2. Click the Save button to export the current model to the OBJ file.
B) Preferences
It contains a set of features in which you can control the different parameters to get the desired output.
C) About
It displays information about the product. It provides the facility to activate your product license at any time.
Commands
Ribbon/Toolbar Icon | Command | Command Description |
---|---|---|
![]() |
OBJExport |
Export the model to OBJ file. |
![]() |
AboutOBJExporter |
Shows information about company and product, can also be used to activate the plugin. |
![]() |
OBJPreferences |
Application settings. |
Installation/Uninstallation
Install:
The installer that ran when you downloaded this app/plug-in from Autodesk App Store, will start installing the app/plug-in.
OR
Simply double-click the downloaded installer to install the app/plugin.
You may need to restart the Autodesk product to activate the app/plug-in.
Uninstall:
To uninstall this plug-in, exit the Autodesk product if you are currently running it. Simply rerun the installer and select the "Uninstall" button.
OR
You can uninstall it from 'Control Panel/Programs and Features' (Windows 7/8.1/10/11), just as you would uninstall any other application from your system.
Additional Information
Known Issues
Contact
Author/Company Information
Support Information
Version History
Version Number | Version Description |
---|---|
6.0.24144.3517 |
Added 2025 support. |
5.2.22277.3432 |
1. Added: 1. Scaling issue fixed. 2. Updated preferences UI. 3. Updated About Us UI. 4 .Export properties with JSON and CSV files. 5. Texture Export (New folder is created). 6. Ungrouping feature. 7. Supports Revit 2024. |
5.1.22042.3377 |
1. Added: 1. File Optimization. 2. Resolved 3D Viewer issue. 3. Reset functionality. 4. Added Preview images in Preferences. |
5.1.21243.3359 |
1. Added: 1. license fixes 2. Open Exported File Location Feature |
5.0.21154.3326 |
1. Added: 1. Material-Wise and Geometry-Wise Sorting 2. Scaling Multiplier Feature 3. Rotate by Feature |
4.7.20272.3249 |
1.Enhancement : Added Support to Revit 2021.1 (Note:For Revit R2021, version should be updated to R2021.1 or latest version available) 2.Enhancement : Added Smart update functionality |
4.6.20020.3182 |
Enhancement: Added license reset functionality. |
4.5.19249.3115 |
Fixed: Issues in license mechanism. |
4.4.19134.3040 |
1.Enhancement:Upgraded licensing system. |
4.3.0.0 |
1.Enhancement : Added support for Autodesk Revit 2020. 2.Fixed : Fixes to license system |
4.2.0.0 |
1. Enhancement : Added support for exporting active views 2. Enhancement : Added model units in OBJ file as comment |
4.1.0.0 |
1.Fixed : Selected entities were not getting exported for some models. 2.Enhancement : Added "Accept terms and conditions" checkbox in Trial license information dialog. |
4.0.0.0 |
1. Enhancement: Added support for Autodesk Revit 2019. |
3.3.0.0 |
1.Feature: Added feature to control the mesh quality of exported model. 2.Fixed: Bug in license activation for Revit 2017. |
3.2.0.0 |
1. Fixed: Bug in GUI license activation due to same license key for Automation and GUI mode. |
3.1.0.0 |
1. Fixed: Export was not working for specific Revit model files. 2. Fixed: Crash while exporting selected entities with texture. 3. Enhancement: Added support for entourage type of entities. |
3.0.0.0 |
1. Update : Added support for Revit 2018. 2. Update : Updated technical support contact details. |
