Merge Hatch Plus
說明
Enhance your hatch workflow with this app, which offers two essential commands:
1. Merge Hatch Plus:
This command enables you to quickly merge multiple hatches into a single, unified hatch entity. With an intuitive dialog box, you can adjust key properties such as pattern, scale, angle, layer, color, and transparency for the merged hatch. The smart auto-selection option allows the app to automatically detect and select all hatches matching the base pattern—eliminating the need for tedious manual picking. The dialog also remembers your last used settings, streamlining repetitive tasks.
Features include:
- Intelligent auto-selection of hatches with the same pattern as the base hatch.
- Selection of multiple hatches to combine their boundaries into one.
- Adjustment of hatch pattern, scale, and angle with real-time feedback.
- Layer selection from a sorted list, with a preview of the selected layer name.
- Color selection using Autodesk® AutoCAD® color dialog, with options for ByLayer, ByBlock, and custom colors.
- Transparency control for the merged hatch.
2. Create Pattern:
This command allows you to generate a hatch pattern file (.pat) from an existing hatch in your drawing. Simply select a hatch, and the command will extract its pattern definition, making it easy to standardize, reuse the pattern in other drawings or share it with colleagues.
Features include:
- Automatic extraction of pattern data from the selected hatch.
- Option to save the pattern file with a user-specified name and location.
Both commands are designed to be fast, convenient, and highly efficient, integrating seamlessly into your AutoCAD environment. Whether you are managing complex hatch patterns or creating custom patterns for future use, this tool helps you save time, reduce repetitive work, and boost overall productivity.
